PROJECT RSD29

6131 DWT multipurpose dry-cargo vessel (modernization of project 0201L tanker)


Purpose - carrying of the general and bulk cargoes (including grain), packaged lumber, timber, scrap-metal, bunched and rolled steel, coil, hazardous cargoes of classes 1, 2, 3, 4, 5, 6.1, 8, 9 in accordance with IMDG Code and category "B" cargoes from IMSBC Code.

# Name Value
1. Main dimension
Length overall, m 129.30
Length on MC of plimsoll mark, m 123.60
Breadth scantlings, m 16.50
Depth, m 6.80
Overall height up to an upper edge
of non-removable parts from BL (not greater than), m
17.70
L x B x H 129.30 x 16.50 x 6.80 = 14 507
2. Draught, m 4.742
3. Deadweight at draught d = 4.742 m, t 6131
4. Endurance, days 15
5. Range, nautical miles 4000
6. Number of cargo holds 4
7. Cargo holds capacity, m³ 8334
8. Double bottom distributed load intensity, t/m² 9.0
9. RS class KM Ice1 R2 AUT1
10. ME power, kW 1 x 1800
11. Rudder and propeller complex 1 FPP +
3 streamline full-balanced rudder
12. Bow thruster, kW 240
13. Auxiliary engines:
diesel-generators, kW 3 x 220
emergency diesel-generator, kW 1 x 90
14. Crew / berth, pers. 11 / 16
15. Speed, knots 10.0
