PROJECT PV05
Running boat
Purpose - transportation of VIP passengers and implementation of pleasure cruising.
| # | Name | Value |
|---|---|---|
| 1. | Main dimension | |
| Length overall, m | 44.16 | |
| Length on DWL, m | 40.73 | |
| Breadth overall, m | 7.015 | |
| Breadth on DWL, m | 6.0 | |
| Depth to the main deck, m | 3.74 | |
| L x B x H | 45.16 x 7.015 x 3.74 = 1 185 | |
| Air draft to an upper edge of non-removable parts at draught d = 1.93 m (not greater than), m |
7.58 | |
| 2. | Draught, m | 1.93 |
| 3. | Passenger capacity: | |
| standard voyage, pers. | 6 | |
| voyage by duration till 8 hours in inland waters basin "R" and "O" category, pers. |
48 | |
| 4. | Endurance: | |
| by fuel stores, days | 10 | |
| by provisions stores, days | 5 | |
| 5. | Range, nautical miles | 1200 |
| 6. | RRR class | O 2.0 A |
| 7. | ME power, kW | 2 x 170 |
| 8. | Auxiliary diesel-generators, kW | 2 x 80 |
| 9. | Crew: | |
| standard voyage, pers. | 6 | |
| voyage by duration till 8 hours in inland waters basin "R" and "O" category, pers. |
10 | |
| 10. | Speed (at draft d = 1.93 m at MCR of ME), knots |
10.8 ±0.5 |
O 2.0 A
